New Build – London
Client

Main contractor

Sector

Residential

Project Type

Installation

Products Used

6 MagnaGrandIP

Onsite Duration

9 days

Location

London

REQUIREMENT

We were asked to specify, install and commission two pumping stations to pump foul and surface/ground water from each of three new houses – a total of six pumping stations. Each surface/ground water pumping station would be supplied with an automatic battery backup system. Following commissioning, we were asked to attend a handover meeting with the planning authorities.

METHOD

• We carried out a site survey to ensure installation would proceed seamlessly and to specify suitable pumps.
• We monitored the construction of the concrete sumps during each phase of the build to ensure all discharge pipework, cable ducts and vents were installed correctly.
• We installed six pump sets and wired everything back to the control panels using cable extensions installed by the client.
• We carried out full wet test and commissioning for each set.

RESULT

• By liaising with the main contractor throughout the work, we facilitated a simpler and more cost effective installation.
• Installation was completed efficiently over a continuous nine day period.
• Cable extensions were routed via the ceiling very early in the construction phase so that the pumps could be installed close to the handover period.
• Each control panel is capable of connecting to either our own telemetric diallers (optional) or the owner’s BMS system. This allows for on-site and off-site monitoring. Additionally, each pumping station has a battery backup high level alarm in case of power failure.





FOCUS ON:



POWERSAFE AUTOMATIC BATTERY BACK-UP SYSTEMS

The PowerSafe range of fully automatic battery back up systems are designed to offer peace of mind for your basement drainage. The system can be used on single or dual pump configurations and is suitable for both ground water and foul waste. It comes complete with a built in GSM telemetry for complete monitoring of your pumped drainage system (not available on the PowerSafe ECO). The PowerSafe is suitable for installing either at the initial building stage, or retrofitting to existing buildings. The system comprises of a PowerSafe control panel, cable cover, battery holder and batteries (number to be specified at time of order).
